AP/Client/Repeater/Bridge
Model :
APE-2408g/APE-2408g-N
Specification
| Standards Compliance | IEEE 802.11b |
| IEEE 802.11g | |
| IEEE 802.3 | |
| IEEE 802.3u | |
| IEEE 802.3af | |
| SDRAM | 32 M Byte |
| Flash | 8 M Byte |
| Radio Frequency Type | DSSS / OFDM |
| Modulation | IEEE 802.11b: CCK,DQPSK,DBPSK |
| IEEE 802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM | |
| Frequency Band | America/FCC: 2.412~2.462 GHz (11 channels) |
| Europe CE/ETSI: 2.412~2.472 GHz (13 channels) | |
| Transmission Power | IEEE 802.11b: 28 dBm@1~11Mbps |
| IEEE 802.11g: 22 dBm@54Mbps; 23dBm@48Mbps; | |
| 25dBm@36Mbps; 26dBm@6~24Mbps | |
| Transmission Rate | IEEE802.11b: 1/ 2/ 5.5/ 11 Mbps |
| IEEE802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54 Mbps | |
| Super G: up to 108Mbps | |
| Access Point Interfaces | Auto MDI/MMDI-X Ethernet 10/100Base-TX: RJ-45 |
| Sensitivity | IEEE 802.11b: -98dBm @ 1Mbps; -93dBm @ 11Mbps, PER < 8% |
| IEEE 802.11g: -95dBm @ 6Mbps; -75dBm @ 54Mbps, PER < 10% | |
| Antenna Type | APE-2408g: Integrated 15dBi flat panel antenna |
| APE-2408g-N: external high gain antenna | |
| Security Systems | 64-bit/128-bit/152-bit WEP encryption; |
| Wi-Fi Protected Access (WPA)/ WPA2) | |
| 802.1x Authenticator | |
| 802.1x Supplicant -TTLS | |
| Wireless Setting | Operation Mode : AP/ Client / Wireless Bridge (WDS) PtP and |
| PtMP (up to 16 links)/ Repeater | |
| Channel Selection (Setting varies by Country) | |
| Adjustable transmit power by 1dBm step | |
| Operating Environment | Operating Temperature: -20 ~ +70°C |
| Power | DC 48 Volt ± 5%; 0.4A (Max.); AC adapter AC 100V ~ 240V |
| Software/Firmware | Site Survey |
| DHCP Client | |
| Suppressed SSID | |
| Spanning Tree settings | |
| Wireless access control by MAC address filter (up to 50) | |
| Multiple SSID with 802.1q VLAN tagging (up to 4 SSIDs) | |
| Web-based configuration via popular browser (MS IE, Netscape...) | |
| Windows "Locator" program to help find IP in DHCP client mode | |
| Firmware upgrade and configuration backup via Web | |
| Reset to default by WebUI | |
| VPN pass-through (PPTP, L2TP, IPSEC) | |
| SysLog | |
| SNMP v1/v2c | |
| MIB support: MIB I, MIB II (RFC-1213) and Private MIB | |
| Support QoS(WMM) | |
| Support Time settings | |
| Network Management | Windows 2000/XP |
| System OS Support | |
| Warranty | One year limited |
Features
- High Output power up to 28dBm
- Fully interoperable with IEEE 802.11b/g compliant devices
- Support Multi-SSID and VLAN function in AP mode
- Enhance user performance and density QoS(WMM) support
- Powerful data security WPA2/WPA/802.1x support
- Range up to 5~10 Km
