High Power Panel Antenna
600MHz to 800MHz 8dbi High Power Panel Directional Jammer antenna
Model :
MP-0608M08A-SF
| Model : | MP-0608M08A-SF |
| LxWxH : | 362x342x33mm |
| Connector : | SMA-Female |
| Styling : | Patch Antenna |
| Gain : | 8dbi |
| -3db Beamwidth : | Horz.58 deg Vert.46 deg |
| N.W. : | 0.8kg |
| Frequency : | 0.6GHz to 0.8GHz |
| Polarization : | Vertical or Horizontal |
| Max Power (C.W) : | 500W |
- Compact design, lightweight
- Superior performance
- Good appearance design
- Compliant with MIL-Stds
- 600MHz to 800MHz 8dbi High Power Panel Directional Jammer antenna
