High Power Panel Antenna
1.2-1.4GHz 8dbi Panel Directional High Power Jammer Antenna
Model :
MP-1214G08A-SF
| Model : | MP-1214G08A-SF |
| LxWxH : | 199x150x28mm |
| Connector : | SMA-Female |
| Styling : | Patch Antenna |
| Gain : | 8dbi |
| -3db Beam-width : | Horz.58 deg Vert.46 deg |
| N.W. : | 0.6kg |
| Frequency : | 1.2GHz to 1.4GHz |
| Polarization : | Vertical or Horizontal |
| Max Power(C.W) : | 300W |
- Compact design, lightweight
- Superior performance
- Good appearance design
- Compliant with MIL-Stds
- 1.2-1.4GHz 8dbi Panel Directional High Power Jammer Antenna
