2MP Network IR Mini Bullet Camera
|
Camera |
||||
|
Sensor |
1/2.8", 2.0 megapixel, progressive scan, CMOS |
|||
|
Lens |
AAL-B2-002FL-36 |
AAL-B2-002FL-60 |
AAL-B2-002FL-120 |
|
|
3.6mm@F1.8Angle of view(H): 80.5° |
6.0mm@F1.8Angle of view(H): 49.9° |
12.0mm@F1.8Angle of view(H): 25.8° |
||
|
Shutter |
Auto/Manual, 1/6~1/8000 s |
|||
|
Min. Illumination |
Colour: 0.06 Lux (F1.4, 50IRE) 0 Lux with IR on |
|||
|
Day/Night |
IR-cut filter with auto switch (ICR) |
|||
|
IR Range |
Up to 30m (98 ft) IR range |
|||
|
S/N |
>52dB |
|||
|
WDR |
Digital |
|||
|
Noise Reduction |
2D/3D |
|||
|
Video |
||||
|
Max. Resolution |
1920×1080 |
|||
|
Video Compression |
H.264/MJPEG |
|||
|
Frame Rate |
1080P (1920*1080): Max. 30 fps; 720P (1280*720): Max. 30 fps; D1 (720*576): Max. 25 fps |
|||
|
Video Streaming |
Triple |
|||
|
9:16 Corridor Mode |
Supported |
|||
|
ROI |
Supported |
|||
|
OSD |
Up to 8 OSDs |
|||
|
Motion Detection |
Up to 2 areas |
|||
|
Privacy Mask |
Up to 4 areas |
|||
|
Network |
||||
|
Protocols |
IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,RTP,RTSP,DNS,DDNS,NTP,FTP, UPnP,HTTP |
|||
|
Compatible Integration |
ONVIF |
|||
|
Interface |
||||
|
Network |
1 RJ45 10M/100M Base-TX Ethernet |
|||
|
General |
||||
|
Power |
12 V DC, or PoE (IEEE802.3 af) |
|||
|
2.0 W (6.4 W with IR on) |
||||
|
Dimensions (L × W × H) |
157.3 × 62.4 ×63 mm (6.2” × 2.5” × 2.5”) |
|||
|
Weight |
0.45 kg (0.99 lb) |
|||
|
Working Environment |
-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing) |
|||
|
Ingress Protection |
IP66 |
|||
Optics
•Day/night functionality
•Smart IR , up to 30 m (98 ft) IR distance
•Optical glass window with higher light transmittance
•IR anti-reflection window to increase
the infrared transmittance
•3D DNR (Digital Noise Reduction)
Compression
•H.264/MJPEG
•Triple streams
•9:16 corridor format
Network
•ONVIF Conformance
Structure
•Wide temperature range: -35°C to 60°C (-31°F to 140°F)
•Wide voltage range of ±25%
• IP66
