IP Box Camera
Model :
AAL-1072
|
Camera
|
|
| Sensor | 2 Mega Pixel 1/3"CMOS sensor |
| Scan Method | Progressive |
| Lens | C-Mount/CS-Mount |
| Number of Effective Pixel (H*V) | 1600x1200 |
| Minimum Illumination | 0.1Lux (AT 30 IRE F1.4 Lens) |
| SNR(max) | 42.3db |
| White Balance | Auto |
| Gain Control | High/Middle/Low, 3 step selection |
| Day and Night | ICR (Auto control by photo sensor; Manual control by CGI) |
| IR-Cut Filter Removable | |
| DNR | Yes |
| Flicker Control | 3 steps selection (Off, 50Hz, 60Hz) |
| Electronic Shutter | Auto, Slow shutter 5 steps selection (Off, 2X, 4X, 8X, 16X ) |
|
Video
|
|
| Video Compression | H.264 BP, MJPEG dual codec, dual streaming, multiple profiles |
| Video Framerate | dual streaming (1280x720/30FPS+640x352/30FPS) |
| Resolution | H.264 : 1600x1200, 640x480/320x240/160x128 |
| 1280x720, 640x352/320x176/192x112 | |
| MJPEG: 1600x1200, 640x480/320x240 | |
| 1280x720, 640x352/320x176 | |
| Bitrate control | Both CBR and VBR, 128kbps ~ 4Mbps |
| Multi-streams |
Maximum triple video streams: 1280x720 H.264/30FPS + 640x352 H.264/30FPS + 1280X720 MJPEG/15FPS 1600X1200 H.264/15FPS + 640x480 H.264/15FPS + 1600X1200 MJPEG/15FPS |
| Digital Zoom (PC side) | Yes, 1/2X, 1X, 2X, 4X |
| Image Rotation | Mirror, Flip, Rotate 180 |
|
Audio
|
|
| 2 Way Audio | Yes |
| Compression | AMR, G.711 @ 64kbps, G.726 @ 32kbps/ Configure bit rate |
|
Network
|
|
| Streaming Protocols | RTSP/RTP/UDP,RTSP/RTP/TCP,RTSP/RTP/HTTP tunneling, |
| LAN Multicast, Multipart-JPEG | |
| Supported Protocols | IPv4, HTTP, UDP, TCP, ICMP, IGMP, ARP, DHCP, NTP, SMTP, |
| FTP, SAMBA, UPnP, PPPoE, DNS, DDNS, RTSP, RTP, RTCP | |
|
3GPP
|
|
| Yes | |
|
Processors and Memory
|
|
| CPU | ARM9 SOC |
| Flash and Memory | 16MB NOR flash, 256MB DDRII |
|
Storage
|
|
| External | 1x Micro SD card |
|
I/O and connectors
|
|
| LAN | 1x RJ45 Ethernet connector with LED |
| Alarm I/O | 1x Alarm-in (2pin), 1x Alarm-out (3pin) |
| Audio | 1x Audio Line-in (3.5 mini jack), |
| 1x Audio Line-out (3.5 mini jack) | |
|
Software
|
|
| Browser | Internet Explorer 6.0 or above |
| Application Software | VMS Application Software |
| OS supported | Microsoft Windows 2000, XP , Vista,Windows 7 |
|
Features
|
|
|
User Setting Date/ Time Setting Video imagecontrol Upload configuration Dynamic DNS Motion Detection Events Triggered Actions Blind Detection Privacy Mask |
|
|
Open API
|
|
| CGI commands to control camera | |
| Media SDK to handle streaming | |
|
Factory Default
|
|
| Button | |
|
Power
|
|
| Power |
DC 12V DC12V/ POE (Option) DC12V/AC24V (Option) |
| Power Consumption | TBD |
|
Physical Properties
|
|
| Dimensions | TBD |
| Weights | TBD |
|
Operating environment
|
|
| Operating temperature | -10°C~ +50°C |
| Storage temperature | -20°C~ +70°C |
| Humidity | 0% ~ 90% non-condensing |
|
Certification
|
|
| CE, FCC Class A, RoHS | |
|
Warranty
|
|
| 24 months | |
Features
- 2 Megapixel 1/3" CMOS Sensor in High Resolution
- H.264/MJPEG Dual Codec & Streaming simultaneously
- Up to UXGA (1600x1200@15fps) / WXGA (1280x720@30fps)
- Digital I/O for External Sensor and Alarm
- Day & Night
- 3D Noise Reduction
- 2 Way Audio Support
- Supports 3GPP
- PoE( Power Over Ethernet) IEEE802.3af
