2MP Vandal-resistant Network IR Fixed Dome Camera
|
Camera |
||
|
Sensor |
1/2.8", 2 megapixel, progressive scan CMOS |
|
|
Shutter |
Auto/Manual, 1/6~1/8000 s |
|
|
AAL-BD2-001FL-36 |
AAL-BD2-001FL-60 |
|
|
Lens |
6 mm |
|
|
Angle of View (H) |
53.2° |
|
|
Day/Night |
IR-cut filter with auto switch (ICR) |
|
|
Min. Illumination |
Colour: 0.06 Lux (F1.6, 50IRE) Black & White: 0.03Lux (F1.6, 50IRE) |
|
|
S/N |
>52dB |
|
|
Image Rotation |
Supported |
|
|
Video |
||
|
Max. Resolution |
1920 × 1080 |
|
|
Video Compression |
H.264,MJPEG |
|
|
Frame Rate |
1080P (1920*1080) 30 fps; 720P (1280*720) 30 fps; D1 (720*576) 25 fps |
|
|
Video Streaming |
Triple |
|
|
OSD |
Up to 8 OSDs |
|
|
Privacy Mask |
Up to 4 areas |
|
|
Audio |
||
|
Audio Compression |
G.711 |
|
|
Two-way audio |
Supported |
|
|
Network |
||
|
Protocols |
L2TP,IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP,PPPoE,RTP,RTSP,Qos,NTP,FTP, HTTP,SNMP,SIP |
|
|
Compatible Integration |
ONVIF, IMOS,API |
|
|
Interface |
||
|
Audio I/O |
Input: impedance 35 kΩ; amplitude 2 V [p-p] |
|
|
Output: impedance 600 Ω; amplitude 2 V [p-p] |
||
|
Alarm I/O |
1/ 1 |
|
|
Network |
10M/100M Base-TX Ethernet |
|
|
General |
||
|
Power |
12 V DC, or PoE (IEEE802.3 af) |
|
|
Power consumption: (5.5W with IR on) |
||
|
Dimensions (Ø x H) |
Φ109 x 81 mm (Ø4.3” x 3.2”) |
|
|
Weight |
0.45 kg (0.99 lb) |
|
|
Working Environment |
-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing) |
|
|
Vandal Resistant |
IK10 |
|
|
Ingress Protection |
IP66 |
|
Optics
•Day/night functionality
•SmartIR, up to 30 m (98 ft) IR distance
•3D DNR (Digital Noise Reduction)
Compression
•Triple streams
•ROI (Region of Interest)
•Customized OSD
Network
•ONVIF Conformance
Structure
•Wide temperature range: -35°C to 60°C (-31°F to 140°F)
•Wide input voltage range of ±25%
•IK10 vandal resistant
•IP66
