2 Megapixel / H.264
|
Camera |
|
|
Sensor |
2 Mega Pixel 1/4” CMOS sensor |
|
Scan Method |
Progressive |
|
Lens |
Fixed Lens 3.6mm |
|
Number of Effective Pixel (H*V) |
1600x1200 |
|
Minimum Illumination |
0.1Lux (F1.6, AGC max.) |
|
Horizontal Resolution |
950TVL |
|
Dynamic Range |
71db |
|
SNR(max) |
42db |
|
DNR |
Auto |
|
White Balance |
Auto |
|
Gain Control |
High/Middle/Low, 3 steps selection |
|
Flicker Control |
Off/50Hz/60Hz, 3 steps selection |
|
Electronic Shutter |
Auto/Slow shutter |
|
Video |
|
|
Video Compression |
H.264 (MPEG-4Part 10/AVC)/MJPEG,Dual codec |
|
Video framerate |
1600x1200@15fps/1280x720@30fps |
|
Resolution |
H.264 : 2M(1600x1200@15fps) 720P(1280x720@30fps) MJPEG : 2M(1600x1200@5fps) 720P(1280x720@15fps |
|
Bitrate control |
CBR and VBR, 128kbps~4Mbps |
|
Multi-streams |
Dual streaming,Multiple profiles 1280x720 H.264@30fps/640x352 H.264(Sub)@30fps/ 1280x720 MJPEG@15fps/ 1600x1200 H.264@15fps/640x480 H.264(Sub)@15fps/ 1600x1200 MJPEG@5fps |
|
Digital Zoom (PC side) |
1/4X, 1/3X, 1/2X, 1X, 2X, 4X |
|
Image Rotation |
Mirror, Flip, Rotate 180° / 90° |
|
Intelligent Video |
|
|
De-noise |
Yes |
|
Motion detection |
Yes |
|
Tamper detection |
Yes |
|
Privacy Mask |
Yes |
|
Audio |
|
|
2 Way Audio |
Bulit-in Microphone / Speaker |
|
Compression |
AMR, G.711 @ 64kbps, G.726 @ 32kbps/ Configure bit rate |
|
Network |
|
|
Streaming Protocols |
RTSP/RTP/UDP,RTSP/RTP/TCP,RTSP/RTP/HTTP tunneling, LAN Multicast, Multipart-JPEG |
|
Supported Protocols |
IPv4, IPv6, HTTP, UDP, TCP, ICMP, IGMP, ARP, DHCP, NTP, SMTP, FTP, SAMBA, UPnP, PPPoE, DNS, DDNS, RTSP, RTP, RTCP, ONVIF |
|
Storage |
|
|
External |
1x Micro SD Card (Maximum 32GB) |
|
Processors and Memory |
|
|
CPU |
ARM9 SOC |
|
Flash and Memory |
16MB NOR flash,128MB DDRII |
|
I/O and Connectors |
|
|
LAN |
1x RJ45 Ethernet connector |
|
Audio |
1x Internal Microphone-in |
|
Software Compatibility |
|
|
Browser |
Internet Explorer 6.0 or above |
|
Application Software |
VMS Application Software |
|
OS supported |
Microsoft Windows 2000, XP , Vista, Windows 7 |
|
Open API |
|
|
|
CGI commands to control camera Media SDK to handle streaming |
|
Factory Default |
|
|
|
Button |
|
Power |
|
|
Power |
DC 12V DC12V/ POE |
|
Power Consumption |
TBD |
|
Demension |
|
|
|
107.9mm(L)x64mm(W)x37.1mm(D) |
|
Weight |
|
|
|
TBD |
|
Operating Environment |
|
|
Operating temperature |
0°C~ +45°C |
|
Storage temperature |
-10°C~ +60°C |
|
Humidity |
20% ~ 80% non-condensing |
|
Certification |
|
|
|
CE, FCC Class B, RoHS |
|
Warranty |
|
|
|
24 months |
Dimension Diagram
|
•2 Megapixel 1/4” CMOS Sensor in High Resolution
•H.264/MJPEG Dual Codec & Streaming simultaneously
•Up to UXGA (1600x1200@15fps) / WXGA (1280x720@30fps)
•Fixed Lens 3.6m
•3D Noise Reduction
•2 Way Audio Support
•Intelligent Video Analytics
•Microphone and Speaker Embedded
•Micro SD Card Supported (SDHC up to 32GB)
•DV12V & PoE Power Over Ethernet IEEE802.3af (Option)
