802.11ah HaLow USB adapter
The USB-HA-001 is a long-range WiFi HaLow USB Type-C adapter that supports sub 1 GHz unlicensed band. WiFi HaLow enables connectivity for many applications such as IP cameras, sensors, etc.
With a USB Type-C connector it is easy to configure by plugging into a laptop / PC and easy to carry and travel with powered by a power bank.
|
CPU |
NXP i.MX6 |
|
HaLow chipset |
Newracom NRC7292 |
|
RAM |
DDR3 256 MB |
|
Flash |
32 MB NOR |
|
Frequency |
915 MHz (US) |
|
Date rate |
Up to 6 Mbps |
|
Channel bandwidth |
1/2/4 MHz |
|
Antenna connector |
SMA female |
|
Interface |
USB Type-C |
|
LED |
Power |
|
Dimensions |
90 x 48 x 19 mm |
1. Newracom NRC7292 HaLow chipset
2. i.MAX 6 powerful ARM SoC
3. USB Type-C connector for power and data
4. AP / Client mode hardware switch
5. SMA external antenna
6. LED indicators
