IEEE 802.11ah sub 1 GHz + WiFi 4 Indoor IoT Router
1.HaLow detachable dipole antenna
2.HaLow antenna SMA connector
3.4x LED indicators
4.MediaTek MT7628 + Morse Micro MM6108
5.1x Fast Ethernet
6.2x WiFi 4 antenna RP-SMA connector
7.2x WiFi 4 detachable dipole antenna
AAP-HA-001 is a WiFi HaLow™ + WiFi 4 Indoor Extender / Router. It allows building long range, ultra-low power WiFi networks
in sub 1 GHz license-exempt bands along with popular WiFi 2.4 GHz share
Internet connection to laptop or smart phone.
WiFi 4 (IEEE 802.11n)
|
Chipset |
MT7628 |
|
Flash |
2 MB |
|
RAM |
128 MB |
|
WiFi standard |
IEEE 802.11n (2.4 GHz) |
|
Channel bandwidth |
WiFi 4: 20/40 MHz |
|
Date rate |
300 Mbps |
|
Antenna connector |
2x RP-SMA |
|
Antenna |
2x 5 dBi dipole antenna |
HaLow (IEEE 802.11ah)
|
Chipse |
Morse Micro MM6108 |
|
WiFi Standard |
IEEE 802.11ah (868/915 MHz) |
|
Channel bandwidth |
1/2/4/8 MHz |
|
Date rate |
150 kbps ~ 15 Mbps |
|
Antenna connector |
1x SMA |
|
Antenna |
1x 3 dBi dipole antenna |
General
|
Ethernet |
1x Fast Ethernet with ESD protection |
|
Button |
1x push-button (reset) |
|
LED
|
1x Power 1x Ethernet 1x WiFi 1x HaLow 1x Reset / System |
|
Power supply |
DC 12V / 1A |
|
Software |
OpenWrt-firmware with source available |
Router Mode Extend existing home WiFi router signal and allow HaLow devices to connect
Router Mode
Extend existing home WiFi router signal and allow HaLow devices to connect As main home WiFi router and allow HaLow devices to connect
