Horn Antenna
500MHz to 8GHz Double Ridged Broadband Waveguide Horn Antenna
Model :
AHA-05M08G-NF
The antenna main body with the bracket using CNC precision manufacturing, and adopt a more weather resistant material aluminum material and the surface through the 6061 and 7071 Aluminum special handling to prevent oxidation.
The AHA-05M08G-NF antenna for local manufacturing in Taiwan, It has many group of spare parts and the peripheral fitting. If you have any question, we may provide service and the adjustment service anytime.
AHA-05M08G-NF each antenna through the RF network analyzer and adjust the testing laboratory to ensure that AHA-05M08G-NF the stability and quality.
Electrical Specifications
| Frequency Range |
500MHz - 8000MHz
|
| 1GHz - 8GHz V.S.W.R |
2 :1 (avg)
|
| Antenna Type |
Horn
|
| Radiation |
Directional
|
| Gain |
3-17 dBi
|
| Antenna Factor |
24 - 40 dB/m
|
| Polarization |
Vertical or Horizontal
|
| Maximum Power |
800W
|
| Vertical Beam-with |
90 -10 Deg
|
| Horizontal Beam-with |
60 - 10 Deg
|
| Impedance |
50Ω
|
| FBR |
10 - 35 db
|
| Antenna Design |
Double-Ridge
|
| Connector |
N-Female
|
Mechanical Specifications
| Length (MAX) |
645mm
|
|
| Diameter (MAX) |
415 x 320 mm
|
|
| Antenna Weght (G.W) |
4500g
|
|
| Accessories (G.W) |
300g
|
|
| Application |
Indoor
|
|
| Paets Material |
Aluminum
|
|
| L Mount Style |
M8 and M6 or 1/4 in
|
|
|
Mounting |
L Type Aluminum
|
|
| Mount Style |
22mm / Long 300mm
|
|
| indexing Ring Mounting |
22mm Tube
|
|
| Storage Temperature |
-20 to +60
|
|
| Operating Temperature |
-10 to +30
|
|
| Operating Humidity |
10%~70% non-condensing
|
|
| Storage Humidity |
5%~50% non-condensing
|
|
| Safety,Emission and other |
RoHS
|
|
Applications
- 500 MHz to 8GHz
- 6061 Aluminum metal alloy
- Stainless Steel N-female
- Taiwan Design ,Make in Taiwan
- High Power 800W (peak) 600W (Cont)
- DC Short lightning protection
- Low VSWR
- Uniform Gain
- Consoidated performance data base
