Open Boundary Quad-Ridged Horn Antenna
Electrical Specifications
Frequency Range
2GHz - 18GHz
V.S.W. R
2.5 :1 (Avg)
Antenna Type
Horn
Radiation
Directional
Gain
2 - 18dBi
Antenna Factor
31 – 42 dB/m
Polarization
Vertical and Horizontal or ± 45 deg
Maximum Power
50W
Vertical Beamwidth
37 Deg
Horizontal Beamwidth
37 Deg
Impedance
50 Ohm
FBR
29 db
Antenna Design
Quad-Ridged
Connector
SMA-Female
Mechanical Specifications
Length x Width
157x157mm
Height
180mm
Antenna Weight (N.W)
879 g
Accessories
1 x L type Aluminum Bracket
8 x M5 socket head cap screws
Application
Indoor
Parts Material
Aluminum
Storage Temperature
-20 to +80
Operating Temperature
-10 to +60
Operating Humidity
10%~70% non-condensing
Storage Humidity
5%~50% non-condensing
Safety, Emission and other
RoHS, WEEE, CE, FCC
- DC Short lightning protection
- Low VSWR
- Uniform Gain
- 2 GHz to 18 GHz Open Boundary Quad-Ridged Horn Antenna
- 6061 Aluminum metal alloy
- Stainless Steel N-female
- EMC testing
