5.1~5.9GHz 12dBi MIMO Antennas
Electrical Specifications
|
Frequency Range |
5100MHz - 5900MHz |
|
V.S.W.R (MAX) |
1.5 :1 |
|
Antenna Type |
Panel |
|
Radiation |
Directional |
|
Gain (MAX) |
12 dBi |
|
Polarization |
Vertical and Horizontal |
|
Maximum Power |
5 Watts |
|
Vertical Beam-width |
Port1 19 Deg / Port2 59 Deg |
|
Horizontal Beam-width |
Port1 86 Deg / Port2 18 Deg |
|
Impedance |
50 Ohm |
|
Antenna Design |
4(2x2)Patch Array |
|
Internal Material |
FR4(Taiwan) |
|
Connector |
N-Female×2 |
Mechanical Specifications
|
Length x Width (MAX) |
130 × 130 mm |
|
Diameter (MAX) |
25 mm |
|
Antenna Weight (G.W) |
150 g |
|
Accessories (G.W) |
180 g |
|
Application |
Indoor / Outdoor |
|
Radom Material |
White ABS + UV |
|
Paets Material |
Aluminum |
|
Mount Style |
1-1.5” Pole Mount |
|
Mounting |
Stainless Steel and Aluminum |
|
Wind Survival |
Greater then 150MPH |
|
Storage Temperature |
-40 to +80 |
|
Operating Temperature |
-40 to +60 |
|
Operating Humidity |
10%~90% non-condensing |
|
Storage Humidity |
5%~90% non-condensing |
|
Safety,Emission and other |
RoHS |
•Superior performance
•Light weight
•All weather operation
•DC Short lightning protection
•Installed for vertical
•Includes tilt and swivel mast mount
•In accordance with customer needs to change the color or features
•5.1GHz – 5.9GHz Frequency Band
•IEEE 802.11a, 802.11n Wireless LAN
•Directional and multipoint applications
•Bluetooth
•Public Wireless Hotspot
•WiFi, RFID
•Wireless Video Systems
