Chipset

•CPU:ASR1803S

Network

•4G LET 3GPP R9 CAT.4•Transfer rate up to 150Mbps

CN version: FDD B1/3/5/8+TDD B34/38/39/40/41+WCDMA B/1/5/8

European version: FDD B1/3/5/7/8/20/28+TDD B38/40/41+WCDMA B/1/5/8

Global version: FDD B1/2/3/4/5/7/8/28/12/17/66+TDD B38/40/41+WCDMA B1/2/4/5/8

Wi-Fi

•IEEE 802.11b/g/n , 2.4GHz  300M

•2*2 MU-MIMO

•Wi-Fi Protected Access™ (WPA/WPA2)

Ports

•1* SIM

•1* LAN

•1*USB2.0

•1 reset key

•2*4G antenna，2 WIFI antenna

Environment

•Working:-20° to 50°C (-4° to 122°F)

•Storage:‑40° to 85°C (‑40° to 185°F)
