Cellular Specification

FrequencyBand

5G NR SA：n78

DataTransferRate (PeakRate)*

5G SA Sub-6：DL 2.2 Gbps；UL 1 Gbps

Antennas

Built-in Omni-directional antennas

WiFi Specification- AX3000M

WiFidatarate

2.4GHz  574Mbps+5GHz  2402Mbps

WiFiProtocol

IEEE802.11 a/b/g/n/ac/ax

FrequencyBand

2.4GHz  574Mbps@2*2 Wi-Fi6

5GHz  2402Mbps@2*2 Wi-Fi6

Flash/DDR

128MB/256MB

Wi-Fi Antennas

Built-in omni-directional antennas

Interfaces

WAN

1 xGigaEthernet(RJ45),autoMDI/MDIX

LAN

3 xGigaEthernet(RJ45),autoMDI/MDIX

SIMCard

1*Nano-SIM interface

Power

1*DC Port,12V/1.5A

LEDIndicators

SYS, 5G,4G,WiFi

Button

RESET,MESH/WPS,POWER

Software Features

Management

Access control, Web GUI, TR069, Device Factory Default Setting

Network

Network selection (5G/ Wired WAN / Auto); Network mode: Router, Bridge ; IPv4/v6 (Dual-stack); DHCP or Static IP address Assignment, DHCP Setting; DHCP Server for LAN Devices Static and Dynamic Routing; MESH; NTP Service Support; etc.

WiFiFeatures

Support Wi-Fi Switch turn on/off, Support Wi-Fi SSID/ KEY setup; Support Encryption: WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3; Support SSID broadcasting; Support Wi-Fi bandwidth setup; Support Wi-Fi channel self-adapt and select; etc.
