5~2400MHz SMATV 4-WAY SPLITTER
Model :
W-2204T-AP/P
Specification:
|
Item
|
Frequency (MHz)
|
W-2204T-AP/P
|
|
Insertion Loss (dB)IN-OUT
|
5-40
|
8.5
|
|
40-1000
|
9.2
|
|
|
1000-1750
|
10
|
|
|
1750-2050
|
11
|
|
|
2050-2400
|
12.3
|
|
|
Mutual Isolation (dB)OUT-OUT
|
5-40
|
22
|
|
40-1000
|
21
|
|
|
1000-1750
|
21
|
|
|
1750-2050
|
21
|
|
|
2050-2400
|
20
|
|
|
Return Loss (dB)IN-OUT
|
5-40
|
10
|
|
40-1000
|
11
|
|
|
1000-1750
|
11
|
|
|
1750-2050
|
11
|
|
|
2050-2400
|
10
|
Features:
- RF shielded Zinc die cast housing, nickel-plated.
- Low insertion loss,high return loss and isolation for CATV, satellite TV & MMDS.
- All ports F-(f) connector,75Ω.
- Grounding terminal provided.
- -AP: Single directional DC pass from all output ports to input port:max. 1A, 30V
- Two pieces of screws attached.
- Light weight and compact size
- Screening factor: Class A.
