8 ports 10/100/1000M GIGA Switch HUB
Model :
AHU-5008G
Specifications
Meets Protocol | IEEE 802.3 10Base-T |
IEEE 802.3u 100Base-TX | |
IEEE 802.3ab 1000Base-T | |
IEEE 802.3x Flow Control | |
Flow control fully supported | Half-duplex: backpressure flow control |
Full-duplex: IEEE 802.3x flow control | |
Filtering/Forwarding Rate | 10Mbps: 14,880pps/14,880pps |
100Mbps: 148,800pps/148,800pps | |
1000Mbps: 148,8000pps/148,8000pps | |
Dimension (mm) | 137(L) x 80(W) x 23(H) |
Weight | 140g |
LED | Power, LAN1~8 |
Antenna | One 2dBi Omni-antenna |
Operation Temperature | 0°C ~ 55°C ambient temperature |
Storage Temperature | -20°C ~ 70°C ambient temperature |
Humidity | 10% ~ 90% (Non-condensing) |
Connector | Power Jack |
8 RJ-45 LAN ports | |
Power requirement | DC 9V / 0.5A |
Power requirement | 12V DC |
Features
- 8-port 10/100/1000M UTP
- Auto MDI-II/MDIX function
- Auto-Negotiation function supported
- Store-and-forward mode supported
