Chip Set

 RTL8197FH-VG4+RTL8812FR+RTL8367RB-VC

 FLASH

 8MB

 DDR2

 64MB

 Wireless rate

 2.4 GHz：300Mbps&2*2

 5GHz：867Mbps&2*2

 Antenna

 4*5 dBi External antenna

 Interface

 1* GE WAN+4* GE LAN

 Button

 1* RESET+1* WPS

 Indicator

 POWER/2.4G/5G/WAN/LAN1/LAN2/LAN3/LAN4

 Wi-Fi Agreement

 IEEE 802.11b/g/n/ac support

 MIMO modalities

MU-MIMO

 Work model

 Routing mode, AP mode, relay mode

 Management approach

 Chinese WEB Remote Management

 State

 System state, interface state, routing table

 Wireless Configuration

 Wi-Fi Basic Parameter Configuration / Blacklist

 Network settings

 Working mode LAN/WAN address setting

 System

 System properties/password modification/backup upgrade/restart

 Setup Wizard

 Quick Configuration Wizard

 MTBF

 >20000 H

power consumption

 ≤9 W

 Working temperature

0℃～40℃

 Storage temperature

-40℃～70℃

 Working humidity

 10%~95%, no condensation

 Storage humidity

 5%~95%, no condensation

 Power adapter

 DC 12V/1A
