MIMO 600Mbps Outdoor Bridge 2.4 / 5GHz Dual Band 2x2 Solution

Model : AAP-2458-4N-MM

AAP-2458-4N-MM Wireless MIMO Bridge provides reliable and predictable Wireless Bridge Connection or/and Wi-Fi Coverage. With these wireless access points you can:


Augment throughput for high-bandwidth wireless applications  Protect your investment in wireless networking  Increase network reliability for high bandwidth applications


Data rates of 600 Mbps (Dual RF) Multiple input, multiple output technology for enhanced reliability  2.4/5GHz

radio module


HARDWARE

Memory

16MB Flash + 64MB SDRAM

LAN

1 x 10/100/1000 BaseT RJ-45 with Auto-MDIX

Power Over Ethernet (POE)

Yes (802.3at)

Enclosure

Metal and Plastic PC Case, IP 68 Verified

Default Button

Yes

LED

Power / RF1 / RF2

Ground

Yes

Anti-static Grade

Contact discharge: 6KV
Air discharge: 8KV

Ethernet Lighting Protector

EthernetLine to Earth 2kv, Line to Line 1kv

Power Requirements

802.3at PoE 48Vdc @0.5A / 100~240 Vac, 50/60 Hz

RADIO

Wireless

2.4 / 5 GHz

Output Power

20 dBm

Sensitivity

-92dBm@6Mbps / -75dBm@54Mbps / -73dBm@HT20 / -72dBm@HT40 (2.4GHz)
-90dBm@6Mbps / -75dBm@54Mbps / -73dBm@HT20 / -70dBm@HT40 (5GHz)

Antenna

4 N Jack Connectors

FEATURE

Operating Mode

Thin AP (Need Controller), Fat AP, Bridge

Channel Bandwidth

20MHz, 40MHz

Data Bandwidth Control

Yes (Throughput / Flow Balance / Online User)

Virtual AP

8 Max.

VLAN / QoS

Yes

Output Power Management

Yes (Manually / Auto)

Max. Client Setting

Yes

Spanning Tree

Yes (802.1d)

Distance Setting

Yes (0-15,000m)

Beacon Interval Setting

Yes (20-1,000)

DTIM Interval Setting

Yes (1-255)

Schedule Reboot

Yes (Hour / Day)

SECURITY

MAC Control

Yes

WEP Encryption

64, 128, 152-bit

802.1x

(EAP-TLS, EAP-TTLS, PEAP)

WPA / WPA2

Yes

Online User Control

Yes

Wireless Isolation

Yes

Hidden SSID

Yes

Firewall

Yes
IP Filter
XDos Prevention
Broadcast Storm
ARP/ ICMP /UDP Protect

VPN

VPN Pass-through (IPsec, L2TP, PPTP)

MANAGEMENT

Web Base Management

Yes

Console

Yes (SSH)

SNMP

V1, V2C, Private MIB, 802.11 MIB

Adjacent AP/STA Scan

Yes

NTP

Yes

Support Log Server

Yes

PHYSICAL

Operating Temperature

-30 ~ 80C

Operating Humidity

10 ~ 95% RH

Weight

1.8 Kg

Dimension

259 x 250 x 75 mm
