PEN Booster

Model : AAM-2408-IDU

The AAM-2408-IDU Wi-Fi Signal Booster is a highly efficient and compact unit designed to increase the performance and range of any 2.4 GHz wireless device. This includes Bluetooth, P2P, P2MP, 802.11b, 802.11b+, 802.11g, and 802.11b+g access points and wireless routers.  The AAM-2408-IDU extends signal range, and in certain conditions, can double the range of these wireless devices. This eliminates the use of an additional radio with its associated data line, power outlet, signal interference, and setup headaches.

The AAM-2408-IDU is the fast and easy way to extend your signal range in any environment.


Frequency Band

2.4GHz ~ 2.5GHz

Signal Type

DSSS

TR Switch Time

< 1µsec

Weight

20g

Size – L*W*H

155mm * 21.6mm *

RF Connector Type

90° RP-SMA Male

Antenna Connector Type

RP-SMA Female

Tx Linear output Power

500 mW / +27 dBm max. @ 11g

800 mW / + 29dBm max @ 11b

Diagnosis LED

Pwr@Green,Tx@Red,Rx@Amber

DC Supply Voltage

6.0V, 1A

Operating Temperature

-0 ~ +40 °C

Supply Voltager

6.0V

Rx Input power

-10 dBm

Tx Input power

+20 dBm

Operating Temperature

-0 ~ +50 °C

Storage Temperature

-40 ~ +90 °C

Features:

Perfect For...

•WIRELESS HOTSPOT

•BRIDGE LINK

•BETWEEN NETWORKS

•WIRELESS LOCAL

•AREA NETWORK

Key Features

•Works with Access Points & Routers

•Increases Signal Distance

•Increases Throughput

•Quick & Easy Installation

•Immediate Results

•No Programming Required

•Complete with Power Supply

pplications

•WLAN 802.11b & 802.11g -

•DSSS on the ISM Band -

•Bluetooth
