wireless-system-802-11b/g

Model : APM-24005g

Specification
Standards Compliance IEEE802.11b/g; IEEE802.3; IEEE802.3u
SDRAM 8 M Byte
Flash 2 M Byte
Radio Frequency Type DSSS / OFDM
Modulation IEEE 802.11b: CCK,DQPSK,DBPSK
IEEE 802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM
Frequency Band America/FCC: 2.412~2.462 GHz (11 channels)
Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
Transmission Power IEEE 802.11b: 20dBm
IEEE 802.11g: 20dBm
Transmission Rate IEEE802.11b: 1/ 2/ 5.5/ 11 Mbps
IEEE802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 8/ 54 Mbps
Super G: up to 108Mbps
Access Point Interfaces Auto MDI/MMDI-X Ethernet 10/100Base-TX: RJ-45
Sensitivity -86dBm @ 11Mbps,PER< 8%;-64dBm @ 54Mbps,PER< 10%
Antenna Type Integrated 12 dBi flat panel antenn
Security Systems 64-bit/128-bit/152-bit/ WEP encryption and Wi-Fi Protected Access(WPA)
Wireless Setting Operation Mode-AP/Wireless Client/Repeater/Bridge(WDS)PtP
and PtMP Mode
Operating Environment Operating Temperature: -10 ~ +70°C
Power DC 12 Volt ± 5%; 1.5A (Max.); AC adapter AC 100V ~ 240V
Software/Firmware Site Survey
DHCP Client
Suppressed SSID
Wireless access control by MAC address(deny or accept)
WPA Support(WPA personal and enterprise)
Web-based configuration via popular browser(MS IE, Netscape...)
Windows "Locator" program to help find IP in DHCP client mode
Firmware upgrade and configuration backup via Web
Reset to default by WebUI
Regulatory Approval FCC Part 15 B (US); CE
Network Management System OS Support Windows 2000/XP
Warranty One year limited
Emissions/Safety CE: EW5N2913
FCC: FD5N2913
ER5N2913
