Wireless System: 802.11b/g
Model :
APM-24005g-N
AP Specification
| Standards Compliance | IEEE 802.11b |
| IEEE 802.3af | |
| IEEE 802.3 | |
| IEEE 802.3u | |
| SDRAM | 8 M Byte |
| Flash | 2 M Byte |
| Radio Frequency Type | DSSS / OFDM |
| Modulation | IEEE 802.11b: CCK,DQPSK,DBPSK |
| IEEE 802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM | |
| Frequency Band | America/FCC: 2.412~2.462 GHz (11 channels) |
| Europe CE/ETSI: 2.412~2.472 GHz (13 channels) | |
| Transmission Power | IEEE 802.11b: 20 dBm |
| IEEE 802.11g: 20 dBm | |
| Transmission Rate | IEEE 802.11b: 1/ 2/ 5.5/ 11Mbps |
| IEEE 802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54Mbps | |
| Super G: up to 108Mbps | |
| Access Point Interfaces | Auto MDI/MDI-X Ethernet 10/100Base-TX: RJ-45 |
| Sensitivity | -86dBm @ 11Mbps, PER < 8%; -64dBm @ 54Mbps, PER < 10% |
| Antenna Type | N-tyype female / External high gain antenna ( optional ) |
| Security Systems | 64-bit/ 128-bit/ 152-bit WEP encryption; Wi-Fi Protected Access (WPA) |
| Wireless Setting | Operation Mode - AP / Wireless Client / Repeater / Wireless Bridge PtP and PtMP Mode |
| Software/Firmware | Site Survey |
| DHCP Client | |
| Suppressed SSID | |
| Wireless access control by MAC address (deny or accept) | |
| WPA Support (WPA personal and enterprise) | |
| Web-based configuration via popular browser (MS IE, Netscape) | |
| Windows "Locator" program to help find IP in DHCP client mode | |
| Firmware upgrade and configuration backup via Web | |
| Reset to default by WebUI | |
| Operating Environment | Operating Temperature: -10 ~ +70°C |
| Power | DC 12 Volt ± 5%; 1.5A (Max.); AC adapter AC 100V ~ 240V |
| Regulatory Approval | |
| Network Management | Windows 2000/XP |
| System OS Support | |
| Warranty | One year limited |
