5~2400MHz SATELLITE FINDER

Model : W-4902

Item
Frequency (MHz)
W-4902
Gain  (dB)
950
0-6.5
2050
0-8
Input Sensitivity (dBµV)
950-2050
77
Output Level (dBµV)
950-2050
102
Connector
Input  port
75Ω, F-(f)
Output port
75Ω, F-(f)
Power Requirement (VDC)
13 ~ 18
Noise Figure (dB)
6
Hum Modulation
--
Output port to port isolation
--
Surge Tolerance
--
Surge Withstand
--
RFI shielding
--

Features:

  • With dial level indicator.
  • Sensitive meter for in-line use. With electronic buzzer.
  • Built-in amplifier compensates insertion loss.
  • Pocket size and light weight.
  • kV IEEE C62.41-1991 category A-3 ring wave and 1kV combination wave surge for all ports.
  • Channel loading output levels, CTB, XM, CSO.
  • With 0/22KHz 13/18V indicate LED and Buzzer
