High Gain Omni Directional Antenna for 2.4GHz&5GHz
Model :
AGP-I250407
Electrical Specification
| Frequency Range | 2.4~2.5;4.9~5.85(GHz) |
| Peak Gain | 4;7(dBi) |
| VSWR | 1.92:1 max |
| HPBW/H | 360°; 360° |
| HPBW/V | 30°; 17° |
| Impedance | 50Ω |
| Polarization | Linear; Vertical |
| Power Handling | 10W |
| Connector | RP SMA Plug |
| Cable | RG-316(Black); L:1.0m |
Mechanical Specification
| Operating Temperature | -10°C~60°C |
| Storage Temperature | -10°C~70°C |
| Humidity | 95% RH |
| Radom Material | ABS+PC |
| Color | White/Blue |
| Dimensions | 83L*43W*197H |
| Weight | 150gfw |
| Mounting Function | Weight Stand |
| Wall Mount | |
| Magnet Mount |
Excluding cable loss
